Model AR-DL3356/27, AR-DL3356/50
AR-DL3356 Range - EsoFit 5-6" 18w LED Baffle Retrofit Trim
By ALL LED
Designed to service the needs of the residential/commercial
market, the Esofit retrofit 5-6” trim is ideal for
replacing existing incandescent, fluorescent and halogen lights with their
superior high powered low wattage LEDs with CRI>90 for true color rendering.
The Esofit Plus installs easily into most Junction Boxes and 5-6” recessed
CANs, including IC and NON-IC housings offering great versatility between
different project requirements. Compatible with most line voltage dimmers.
Features
- Dimmable on most leading/trailing edge 120V dimmers
- 16 LED's, 90° Beam Angle
- Lightweight Aluminum Body
- Easy
installation - E26 socket & quick connector
- White Bezel with White Baffle
- IC rated (when used in IC rated CAN)
- High Color Rendering of CRI>90
- (L70) at 50,000 hours lifetime
- Title
24 High Energy Compliance for California
- Suitable for wet locations
- Available in 2700K & 5000K only. Once stock is gone item will be discontinued
- Energy Star Rating
- 1 Year Warranty
AR-DL3356- 1200lm
Compliance & Approvals
- Model
- AR-DL3356/27, AR-DL3356/50
- SKU
- AR-DL3356/27, AR-DL3356/50
- Brand
- ALL LED
- Dimming
- Line Voltage Dimming
- Input Voltage
- 120v AC
- Beam Angle
- 90°
- Lumen
- ≤1200 Lumens
- Watts
- 18w
- CCT (Color Temp.)
- 2700K & 5000K (Select Fixed Color Temperature when Ordering)
- CRI (Color Rendering Index)
- CRI 90
- Wet Location Suitable
- Wet Location Suitable
- Operating Temperature
- -4°F - 104°F
- Warranty
- 5 Year Warranty
- Lifetime (Hours)
- 50,000 Hours
- Applications
- Residential & Commercial
- Finish
- White
- Construction
- Aluminium Body
- Dimensions
- 7.47" x 3.54" (Overall Diameter x Depth) Cut Out Diameter 4.95"
- Energy Star
- ☑
- Title 21 - Ja8
- ☑
- FCC
- ☑
- UL/cUL
- cUL Listed
