AL-R880D/CCT/** - Sabre 8' x 4″ RECESSED Linear Light Engine

ALL LED Sabre 8' Linear Recessed (Grid/ Drywall Flange / Trimless Flange (Black/White)

The New ALL LED SABRE Architectural Light Engine Range available in 2/3/4/8ft leads the market in form and function. Sabre is a high quality luminaire which is available in matching formats for recessed, Grid Ceiling compatible and fully recessed 'trimless', suspended up/down and wall. This LED Light engine fixture is designed for Recessed mounting features CCT Selectable, watt selectable to cover a wide range of applications.

Features

• 2'/ 3'/ 4'/ 8' Linear Light Engine - Surface/recess Mount

• Suitable for Drywall ceiling (Recessed flange or Trimless flange) or most 15/16" and 9/16" Grid ceiling types

• Integral LED Driver

• Watt & CCT Selectable (3000K / 3500K / 4000K)

• Add suffix to part number /W for White or /BK for Black Finish*

• 0-10V Dimmable

• Power:

One 120v Power Point for a 40ft Continuous Run

One 277v Power Point for a 100ft Continuous Run

• Straight joiner & Light up 90° "L" corner joiner module available

• Designed for easy maintenance access from below

• Suitable for Damp Location

• Add suffix; /EM for Emergency, /MS for Sensor

• Integrated Emergency Option (Remote Emergency Option available)

• Input Voltage 100-277V AC

• (L70) at 50,000 Hours Lifetime

• 5 Year Warranty

• Mounting fixing options; Recess Flange, French Key Trimless, T-Grid

Fixing or Custom Installation Fixing to suit ceiling type must be confirmed

when ordering.

• Sabre is a range of complimentary light engines available in; 2'/ 3'/ 4'/ 8' lengths and fully

recessed (trimless), recessed, surface, suspended up/down, and wall fixture (sold

separately) with Emergency and Sensor options.

MATCHING; FULLY RECESSED, RECESSED, SURFACE MOUNT/PENDANT FIXTURE OR WALL FIXTURE ALSO AVAILABLE (SOLD SEPARATELY)
